JIYI TERRAIN RADAR MODULE
₹19,500.00
- JIYI Terrain Radar Module for K++ V2, KX Flight Controller
- This module uses millimeter-wave radar technology
- The ground-like radar module has stable detection performance and good environmental applicability
- It has strong anti-interference ability
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Terrain Following Radar
The terrain following radar module uses millimeter-wave radar technology. Through continuous scanning of the radar, the aircraft can sense the terrain change in the flight direction, and adjust the flying height in time according to the terrain and crop height to achieve ground-like flight and ensure uniform spraying in flight. The ground-like radar module has stable detection performance and good environmental applicability, strong anti-interference ability, not affected by light, long detection distance and has the characteristics of all weather and all day.
Specifications:
Product size: 82.4 x74.2x20mm
Weight: <50g
Modulation Mode: FMCW
Center Frequency: 24.125GHz
Usage Environment: No obstruction below
Try to stay away from water mist
Altimetry range: 0.3-15m (Relative to the ground)
Altimetry Accuracy: 0.05m
Output Frequency: 50Hz
Power Consumption: 1.5W @25℃
Working Voltage: 6-28V
Working Temperature: -20℃ to 85℃
Protection Level: IP67
Output Interface: CAN
1 Item
Comments (0)
No customer reviews for the moment.
10 other products in the same category:
- Mini Crossbow Mini Antenna Tracker
